Official Arduino UNO EK (एक) R4 Minima Made in India | 48 MHz Arm Cortex-M4 processor USB 2.0 USB-C UART SPI I2C CAN 256 kB Flash Memory 14 PIN GPIO.

Official Arduino UNO EK (एक) R4 Minima Made in India | 48 MHz Arm Cortex-M4 processor USB 2.0 USB-C UART SPI I2C CAN 256 kB Flash Memory 14 PIN GPIO. - Image 3

Official Arduino UNO EK (एक) R4 Minima Made in India | 48 MHz Arm Cortex-M4 processor USB 2.0 USB-C UART SPI I2C CAN 256 kB Flash Memory 14 PIN GPIO.

₹699.00

Sort Description :

Made in India 32-bit Arduino board.
Renesas R7FA4M1AB3CFM, 48 MHz Cortex®-M4 processor.
256 kB Flash, 32 kB SRAM, 8 kB EEPROM.
Compatible with older Arduino UNO shields.
Advanced peripherals: ADC, DAC, RTC, CAN bus.
Supports 6-24 V input and USB-C® power.

The Arduino UNO एक R4 Minima is a next-generation development board featuring the powerful Renesas RA4M1 32-bit microcontroller. Designed for enhanced performance, it offers increased processing power, expanded memory, and advanced onboard peripherals—making it a significant upgrade from its predecessors. Staying true to the trusted UNO form factor and 5V operating voltage, the UNO एक R4 Minima ensures seamless compatibility with existing shields and accessories. Perfect for beginners and professionals alike, this board integrates smoothly into the Arduino ecosystem, empowering users to build more complex and demanding projects without compromising reliability or ease of use. Note: Refer to the datasheet in the ATTACHMENTS section for more details about the product.

Features:

UNO Form Factor Compatibility: Maintains same form factor, pinout, and 5V logic as UNO R3 for easy shield and project integration.
Expanded Memory & Faster Clock: More memory and higher clock speed for complex and precise tasks.
Enhanced On-board Peripherals: Includes 12-bit DAC, CAN BUS, and OP AMP for advanced functionality.
24V Input Support: Accepts up to 24V input, ideal for motors, LEDs, and actuators using a single power source.
Built-in SWD Connector: Enables easy debugging with external tools for efficient project development.

Package Includes:

1 x Official Arduino UNO EK (एक) R4 Minima Made in India

Microcontroller:	R7FA4M1AB3CFM
Processor	48 MHz Arm® Cortex®-M4
GTIN	7630049205246
Flash Memory (Kbytes)	256
SRAM Memory (KB)	32
EEPROM	8-kByte
Input Voltage (V):	6 to 24
Connectivity	CAN, I2C, SPI, UART
Shipping Weight 0.04 kg	Shipping Dimensions 9 × 7 × 3 cm

1 Year Warranty

This item is covered with a supplier warranty of 1 year from the time of delivery against manufacturing defects only. In case of manufacturing defects or issues, we will replace the part after warranty confirmation by our technical team, but we won’t offer refunds or replace the entire product.
